OPERATING INSTRUCTIONS & PARTS MANUAL
SPECIFICATIONS
POWER SUPPLY REQUIREMENTS 120 V, 60 Hz
MOTOR Single Phase, Dielectric Oil Filled
HORSEPOWER 1/6 HP
CIRCUIT REQUIREMENT 15 A (minimum)
CONSTRUCTION
MOTOR HOUSING Thermoplastic
MOTOR SHAFT Stainless Steel
IMPELLER Thermoplastic
PUMP DISCHARGE (2) 3/4 in. Brass Hose Fittings
PERFORMANCE (Gal/hr)
Model HP
Discharge Head (Lift Distance)
0 ft 5 ft 10 ft 15 ft 20 ft 25 ft
WWB 1/6 1350 1190 1010 815 600 360
®
GLOW
WITH MOTOR SHUT-OFF PROTECTION
