WBOX Technologies 0E-21D28WDR User Manual

High-Resolution IR Camera
User Manual
Technical Specifications
Issue V1.0 (2018-05-11)
87
Specifications
0E-13D28
0E-13BF36
CAMERA
Image Sensor
1/2.7” Progressive Scan CMOS
Min. illumination
Color :0.2Lux@(F1.2,AGC ON)
B/W: 0 Lux@(IR LED ON)
Day & Night
ICR
Shutter Speed
1/1-1/10000
Auto Iris
Fixed
Wide Dynamic Range
dWDR
Digital Noise Reduction
2D/3D
Lens
2.8mm
3.6mm
FOV
90°
85°
IR LED
18pcs
IR Range
30m
Video Compression
H.264High/Main/Baseline Profile, MJPEG
Bit Rate (CBR/VBR)
Mainstream:500kb-12000kb; Sub stream:100kb-6000kb
Audio Compression
G.711 ,RAW_PCM
Max. Resolution
1280*960/30fps
Stream
Stream1 1280*960
Stream 2 D1 to QVGA
Image Setting
Rotate Mode, Saturation, Brightness, Contrast, Sharpness
HLC
Yes
9:16 Corridor mode
Yes
ROI
Yes
Defog
N/A
NETWORK
