WBOX Technologies 0E-RCKMT1500 User Manual

40 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

COPYRIGHT © 2019 ADI

USER’S MANUAL

Rackmount Series

0E-RCKMT1000 / 0E-RCKMT1500 / 0E-RCKMT2200

K01-1101046-02

EN

Questions and Answers:

K
kristiefrazierJul 25, 2025
What to do if WBOX Technologies 0E-RCKMT1500 outlet does not provide power?
- N
  Nicole ReedJul 25, 2025
  If the outlet on your WBOX Technologies UPS isn't providing power, there are several potential causes. First, the circuit breaker may have tripped due to an overload. To resolve this, turn the UPS off, unplug at least one piece of equipment, wait 10 seconds, reset the circuit breaker, and then turn the UPS back on. Alternatively, the batteries may be discharged; in this case, recharge the unit for at least 8 hours. Also, uncritical outlets may have turned off automatically due to an overload; push the toggle button to turn them back on.
Y
yallenAug 2, 2025
Why WBOX Technologies 0E-RCKMT1500 will not turn on?
- M
  Mary MorganAug 2, 2025
  If your WBOX Technologies UPS won't turn on, it could be due to a few reasons. The on/off switch is designed to prevent damage from rapid cycling. Try turning the UPS off, waiting 10 seconds, and then turning it back on. Also, ensure the unit is properly connected to a 110/120V 60Hz outlet.
R
Robert EdwardsAug 10, 2025
Why WBOX Technologies 0E-RCKMT1500 does not perform expected runtime?
- D
  Diana GreenAug 10, 2025
  If your WBOX Technologies UPS isn't providing the expected runtime, it might be because the batteries are not fully charged. To fix this, recharge the batteries by leaving the UPS plugged in. If the issue persists, it is possible that the batteries are degraded.
A
Aaron HoffmanAug 16, 2025
What to do if WBOX Technologies 0E-RCKMT1500 Power Management Software is inactive?
- E
  Eric KellyAug 17, 2025
  If the Power Management Software for your WBOX Technologies UPS is inactive, first ensure that the serial or USB cable is properly connected to the UPS unit, using the cable that came with the unit. If it's connected, try another port on your computer. As an additional step, you can shutdown your computer and turn the UPS off, wait 10 seconds, and then turn the UPS back on to reset the unit.
