Spare parts list, wearing parts list, consumables list
Hint !
Spare parts, wearing parts or consumables means can be ordered at your service part-
ner or dealer.
Spare parts list
Device
Pos.
Description
Item no. WDT
Dosing pump
4
Protective cover for pumping housing SA, transparent
14259
12
Lock washer for roller carrier SA, blue
13633
15
Hose holder with hose SA-3.2 Viton
13358
17
Roller carrier for hose pump, yellow
12609
-
Suction hose PE 4x1- 1.5 m
Options
Device
Pos.
Description
Item no. WDT
Dosing set
-
Dosing set compete
12596
-
Dosing valve VA, complete, 3/8“ - 4x1mm
-
3m dosing hose PTFE 4x1 mm
Dosing valve
-
Dosing valve VA, complete, 3/8“ - 4x1mm
15108
-
Sealing ring 10x2x2mm
10421
-
Hose connection 4x1mm
10410
-
Dosing pipe PTFE 4x1mm (internal diameter)
10432
Console
-
Console with round jar with wide neck, 1.5 litres
13892
-
Console for canister, 10 litres
14391
Wearing parts list
Wearing parts are excluded from the warranty of 2 years. We provide a warranty for half a year on those parts.
Device
Pos.
Description
Item no. WDT
-
Hose set SA 3.2 x 1.6-Viton – 2x
12782
17
Roller carrier for hose pump, yellow
12609
List of consumables
Fragrances: A list of the current fragrances is available from WDT.
10 Appendices
 Commissioning protocol
 Maintenance protocol
Own notes
