Fragrances dosing, type DUFTDOS-0-Compact
Index: 01 Change date: 01/12/2017 Operating instructions no.: BA DW 017-01 Duftdos-0-Compact EN 17630.docx Page 8 of 21
Technical data
DUFTDOS-0-Compact
Dimensions and weights:
External dimensions
approx. 0.14 x 0.07 x 0.8m (HxWxD)
Space requirements
approx. 0.50 x 0.30 x 0.30m (HxWxD)
Space requirements incl. operation and
maintenance
approx. 2.00 x 0.60 x 0.90m (HxWxD)
Weight
approx. 0.6kg
Connection data
Connection dosing
Dosing hose Ø 6/4mm
Electrical connection
230 VAC/50Hz, 6W
Protection type
IP65
Operating data:
Medium temperature
5-35°C
Environmental temperature in utility
room
5-35°C
Humidity in utility room
max. 70%
Suction height
max. 2m
Ventilation and extraction
Recommended for the utility room
Operating pressure
max. 1.5 barg
Transport power in the continuous mode
max. 3l/h
Transport / storage
The device must be checked for possible transport damage immediately after receipt.
ATTENTION !
The device can get damaged by frost or high temperatures. Prevent exposure to frost
during transport and storage! Do not store the device next to objects with high heat
radiation or directly exposed to sunlight. The device may only be transported and
stored in its original packaging. Careful handling must be ensured.
The roller carrier of the dosing pump is not installed during transport and storage. This prevents deformation
of the hose.
Storage of fragrances / chemicals
DANGER !
The safety data sheets of the fragrance manufacturers have to be considered with re-
gard to storage!
The following points must be considered, among others:
 Fragrance concentrates may only be stored in appropriately marked, original plastic containers.
 The fragrance concentrates must be stored in a separate storage room.
 The environmental temperature may not exceed 20°C.
See at this regard also Section 2.2.1 “Handling of chemicals, risks to persons and the environment“.
CAUTION !
Follow locally valid rules for the handling of chemicals!
