Fragrances dosing, type DUFTDOS-0-Compact
Index: 01 Change date: 01/12/2017 Operating instructions no.: BA DW 017-01 Duftdos-0-Compact EN 17630.docx Page 9 of 21
4 Installation
The work described here may only be performed by appropriately trained specialist staff or by a specialist
company.
Selecting the place of installation
The place of installation must have the following characteristics:
1. The place of installation must be protected against frost.
2. The device must be protected against direct sunlight.
3. An electrical mains connection must be available.
4. Good air supply and extraction are recommended for the installation room.
Installation information (installation suggestion)
The device is assembled in the technical room at a wall. The dosing pipe to the steam pipe must be as short
as possible.
Consider the space required for operation and maintenance of the device, see Section 3.4 Technical data.
Warning and information signs according to the locally valid accident prevention regulations are to be
provided at the intended positions.
Mounting diagram
