SERIES XT INSTALLATION, OPERATION AND SERVICE MANUAL
8
SECTION 5: SPECIFICATIONS
Estimated weight table apply to both upright and
horizontal units of the same model. See Page 8,
Ta b l e 2 .
Unless otherwise requested, all direct-fired air
handlers are set-up to accept an external static
pressure (ESP) of 1 in wc (2.5 mbar). The external
static pressure is the sum of all accessories and any
attached ductwork. See Page 9, Table 4 and Table 5
for static pressure accessories. If more external static
pressure is required, this needs to be requested with
the order as required motor horsepower (HP) may
increase from the specifications given on Page 8,
Ta b l e 3 .
Table 2: Estimated Shipping Weights
* Includes Casing, Motor, Control Panel and Manifold
** Includes Weight of Filters
*** Total Quantity of 4 legs
**** Mounted to Intake Hood
Table 3: Performance
All information provided in this table is based on the assumption that unit is installed at an altitude below 2000 feet (609.6 meters).
CF = Consult Factroy
** dBA is measured at 10' (3 m) from unducted discharge.
*** Maximum Inlet Gas Pressure:
Model XT-112 = 14 in wc (34.9 mbar)
Model XT-115-XT-130 = 5 psi (344.7 mbar)
Model
XT-112 XT-115 XT-118 XT-125 XT-130
lbs kg lbs kg lbs kg lbs kg lbs kg
Air Handler* 589 267 994 451 1290 585 1946 883 2877 1305
Filter Section** 118 54 210 95 282 128 407 185 439 199
Filtered Mix Box** 301 137 443 201 539 245 800 363 1156 524
Inlet Hoods 145 66 276 125 346 157 499 226 539 244
Upright Legs*** 75 34 99 45 137 62 176 80 214 97
Horizontal Legs*** 102 46 102 46 102 46 102 46 102 46
Moisture Limiters**** N/A N/A 120 54 120 54 210 95 260 118
Skid 147 67 249 113 324 146 486 220 719 326
Airflow
CFM (m
3
/h)
Model
Motor HP at Noted External
Static Pressure (in wc)
dBA at Noted External
Static Pressure
(in wc)**
Heat Output at
Maximum
Temperature Rise
(Btu/h) x 1000
Minimum
Inlet Gas
Pressure
in wc
(mbar)***
Manifold
Size in NPT
(mm)
00.250.50 0.75 1.00 0 0.50 1.00 NG LPG
1,000 (1,700) XT-112 1111162 66 70 97 86 7.1 (17.6) 0.75 (19)
2,000 (3,400) XT-112 2222260 66 70 194 173 7.1 (17.6) 0.75 (19)
3,000 (5,100) XT-112 2222260 65 70 292 259 7.1 (17.6) 0.75 (19)
4,000 (6,800) XT-112 3 3 3 3 3 62 65 70 389 345 7.1 (17.6) 0.75 (19)
5,000 (8,500) XT-115 3 3 3 3 3 58 63 68 594 486 7.1 (17.6) 1.0 (25)
6,000 (10,200) XT-115 5 5 5 5 5 58 62 67 712 583 7.1 (17.6) 1.0 (25)
7,000 (11,900) XT-115 5 5 5 5 5 59 62 66 831 680 7.1 (17.6) 1.0 (25)
8,000 (13,600) XT-115 5 5 5 5 5 60 63 66 950 777 8.9 (22.1) 1.0 (25)
9,000 (15,300) XT-115 7.5 7.5 7.5 7.5 7.5 61 64 67 1,069 874 11 (27.3) 1.0 (25)
10,000 (17,000) XT-115 7.5 7.5 7.5 7.5 7.5 62 65 68 1,188 972 13.4 (33.3) 1.0 (25)
11,000 (18,700) XT-118 7.5 7.5 7.5 7.5 7.5 64 66 68 1,306 1,069 7.7 (19.2) 1.25 (32)
12,000 (20,400) XT-118 7.5 7.5 7.5 7.5 7.5 66 68 69 1,425 1,166 8.9 (22.1) 1.25 (32)
13,000 (22,100) XT-118 10 10 10 10 10 67 69 CF 1,544 1,263 10.3 (25.6) 1.25 (32)
14,000 (23,800) XT-118 10 10 10 10 10 69 CF CF 1,663 1,361 11.7 (29.1) 1.25 (32)
16,000 (27,200) XT-125 10 10 10 10 10 70 72 76 1,900 1,555 6.9 (17.2) 1.5 (38)
18,000 (30,600) XT-125 15 15 15 15 15 70 74 77 2,138 1,749 8.3 (20.6) 1.5 (38)
20,000 (34,000) XT-125 15 15 15 15 15 70 74 77 2,376 1,944 9.9 (24.6) 1.5 (38)
22,500 (38,200) XT-125 20 20 20 20 20 71 74 77 2,673 2,187 12.2 (30.3) 1.5 (38)
25,000 (42,500) XT-125 25 25 25 25 25 72 75 77 2,970 2,430 14.7 (36.6) 1.5 (38)
27,500 (46,700) XT-130 25 25 25 25 25 71 73 75 3,267 2,673 7.7 (19.2) 2.0 (51))
30,000 (51,000) XT-130 25 25 25 25 25 73 75 76 3,564 2,916 8.9 (22.1) 2.0 (51)
32,500 (55,200) XT-130 30 30 30 30 30 75 76 77 3,861 3,159 10.2 (25.4) 2.0 (51)
35,000 (59,500) XT-130 40 40 40 40 40 77 77 79 4,158 3,402 11.7 (29.1) 2.0 (51)
37,500 (63,700) XT-130 40 40 40 40 40 78 79 79 4,455 3,645 13.4 (33.3) 2.0 (51)
40,000 (68,000) XT-130 50 50 50 50 50 80 CF CF 4,752 3,888 15.2 (37.8) 2.0 (51)
