SECTION 22: REPLACEMENT PARTS
77
Table 22: Blower Spare Parts
Table 23: Remote Spare Parts
Table 24: Motor Control Spare Parts
Model XT-112
XT-115 XT-118 XT-125 XT-130
1000-2000 CFM 2000-4000 CFM
Blower 62924 62923 P-000315 P-000316 P-000317 P-000318
Bearing - - P-000627 P-000630 P-000633 P-000636
Shaft - - P-000628 P-000631 P-000634 P-000637
Wheel - - P-000629 P-000632 P-000635 P-000638
Description Remote Panel Part Number
Rocker Switch Center Off SDC & DTC 19899
Rocker Switch DPST All 19898
Remote Temperature Selector DTC 07390
Thermostat with Timer DTC 28688
Amber Status Light All 22550
Temperature Selector Basic Remote & SDC 07345
Thermostat SDC 07837
40VA Transformer DTC 07037
Terminal Block All 28057
460/3/60
1 1.5 2 3 5 7.510152025304050
Overload 28706 28710 28710 28709 28708 28711 28712 28713 28714 28715 28716 28717 28718
Starter 33810 33810 33810 33810 33810 33811 33812 33813 33814 33815 33816 33817 33818
Fuse 25128 25091 25092 25093 25094 25095 25096 25097 25099 25100 25101 25103 25106
Fuse
Block
25130 25130 25130 25130 25130 25130 25130 25130 25131 25131 25131 25132 25132
230/3/60
1 1.5 2 3 5 7.510152025304050
Overload 28709 2878 28708 28711 28712 28713 28714 28716 28717 28718 28719 28720 28720
Starter 33810 33810 33810 33811 33812 33813 33814 33816 33817 33818 33819 33819 33820
Fuse 25093 25114 25094 25115 25096 25116 25099 25101 25103 25106 25108 25109 25117
Fuse
Block
25130 25130 25130 25130 25130 25130 25131 25131 25132 25132 25906 25906 25906
575/3/60
1 1.5 2 3 5 7.510152025304050
Overload 28705 28706 28710 28710 28708 28707 28711 28712 28713 28714 28714 28716 28717
Starter 33810 33810 33810 33810 33810 33810 33811 33812 33813 33814 33814 33816 33817
Fuse 18605 18609 18614 28610 18594 18598 18599 18607 18608 18622 18616 18619
Fuse
Block
18505 18505 18505 18505 18505 18505 18505 18505 18504 18504 18504 22648
