OPERATING INSTRUCTIONSWEBASTO DBW SERIES HEATERS
Heater
on/off
manual
Set
Timer
on/off
Display
Timer
on/off
Hour
Minute
Hour
Day
AND
Set
Timer Programming (Timed Heater Start Setting)
• Depress buttons ‘Set’ and ‘Timer on/off’ simultaneously to start programming.
NOTE: The yellow ‘T’ LED will flash
• Depress button ‘Day’ to select day heater is to come on.
• Depress button ‘Hour’ to select correct hour.
• Depress button ‘Minute’ to select correct minute.
• Depress button ‘Set’ to end timer programming.
NOTE: If ‘Set’ button is not depressed within 15 seconds, programming function
will end automatically
