• Power Supply / Battery Connections
Power Supply: The LS-350 comes with 48VDC Power Supply. Connect it to the step-down input. It’ll
feed 12VDC to the LS-350 board.
Battery: Connect the 12VDC battery on the Battery input.
The LS-350 enclosure is not certified for the containment of alternating current (AC). Electing
to do so will result in the nullification of the warranty and potential harm to the product. It is
strongly advised to position the power supply external to the enclosure using the provided
bracket.
