Webb WEELT650 - Parts List

PARTS LIST
No. Webb Part No Webb Description QTY No. Webb Part No Webb Description QTY
1
WE132-
301070612
Left Handle Cover 1 27
WE132-
301029411
Right Housing 1
2
WE131-
104030136
Self-Tapping Screws 38 28
WE131-
301029393G
Decorative Block 1
3
WE132-
301029413
Left Handle 1 29
WE132-
104030135
Self-Tapping Screws 7
4
WE131-
301990135
Pressing Line Plate 2 30
WE132-
103060096
Connector Spring 1
5
WE132-
102020111
Positive microswitch 1 31
WE132-
301029412
Left Housing 1
6
WE131-
301070613B
Trigger 1 32
WE132-
301029416
Housing Cover Left 1
7
WE131-
103060034
Hand Spring 1 33
WE132-
301029421
Left Connector 1
8
WE131-
102080445
Inner Wire 1 34
WE132-
301070617
Shake Head Button 1
9
WE131-
102070627
BS Plug & Cable 1 35
WE132-
105020003
Rubber Insert 2
10
WE131-
301021046
Cable Sleeve 1 36
WE132-
102010382
650W Motor 1
11
WE131-
1029901010
Wiring Terminal 1 37
WE131-
301029386
Motor Bracket 1
12 WE132-4100116 Spring Wire Assembly 1 38
WE131-
104030334
Flat Head Screws 2
13
WE132-
301029414
Right Handle 1 39
WE132-
301070593
Roller Support 1
14
WE132-
301070615
Reft Handle Cover 1 40
WE132-
104040175
Roller Bolt 1
15
WE132-
301029418
Auxiliary Handle Upper
Cover
1 41
WE132-
301070594
Trimming Roller 1
16
WE132-
301029419
Auxiliary Lower Handle 1 42
WE132-
103990616
Cap Bearing Clamp 1
17
WE131-
301023043B
Right Adjustable
Handle Knob
1 43
WE132-
104020003
Hexagon Nut 1
18
WE132-
103060258
Spring 1 44
WE132-
103990721
Plant Protector 1
19
WE131-
301023045
Left Adjustable Handle
Knob
1 45
WE132-
301029410
Guard 1
20 WE132-4040109 Telescopic Shaft 1 46
WE132-
104010083
Spring Washer 1
21
WE131-
104030421B
Self-Tapping Screws 2 47
WE132-
104010014
Flat Washer 1
22
WE132-
301029422
Rotating Joint 1 48
WE132-
104040161
Guard Screw 1
23
WE131-
301070624B
Rotate Button 1 49
WE131-
301070651
Full Automatic Fan
Assembly
1
24
WE131-
103060276
Button Spring 1 50
WE131-
104020030
Flange Nut 1
25
WE132-
301029420
Right Connector 1 51
WE131-
301029099
Nut Cover 1
26
WE132-
301029415
Housing Cover Right 1 52
WE131-
301100001
Spool & 1.5m Line 1
53
WE131-
301021041
Spool Cover 1
