Webb WEER33 - Parts List

PARTS LIST
ITEM PARTNUMBER DESCRIPTION QTY ITEM PARTNUMBER DESCRIPTION QTY
1 WE124-4080062 SwitchBoxAssembly 1 34 WE124-105990072A RibbedBelt 1
2 WE124-104030424 ST4.2*25Screw 2 35 WE124-103050242 Bearing 1
3 WE124-103080038 TopHandleAssembly 1 36 WE124-103990417 BearingHolder 4
4 WE124-301070859 CableHanger 1 37 WE124-301070918 RearWheel 2
5 WE124-301070858 CableClip 2 38 WE124-103990797 AxleClamp 4
6 WE124-104040122 M6X45Bolt 2 39 WE124-103050251-1 BackAxle 1
7 WE124-103020131 RightLowerHandle 1 40 WE124-301070857 AxleBracket 1
8 WE124-301070851 HandleKnob&Nut 2 41 WE124-301070914 LowerDeck 1
9 WE124-103020132 LeftLowerHandle 1 42 WE124-301070703 Lockpin 2
10 WE124-301070912 HandleAdjustmentButton 2 43 WE124-301070706 LockpinSeat 2
11 WE124-103060194 HandleAdjustmentSpring 2 44 WE124-301070849-1 ConnectingRod 1
12 WE124-301070826 Pin 2 45 WE124-103990861 SupportBar 1
13 WE124-301070827 RightSupportSeat 1 46 WE124-103040135 ST4.2X12Screw 3
14 WE124-301070396F MotorCoverCarryHandle 1 47 WE124-103060299 TensionSpring 1
15 WE124-301070910 MotorCover1 1 48 WE124-301070915 FrontWheel 2
16 WE124-301070911 MotorCover2 1 49 WE124-103050250 FrontAxle 1
17 WE124-301070913 UpperDeck 1 50 WE124-103990812 LocatingPin 1
18 WE124-301070854 LeftSupportSeat 1 51 WE124-301070845 HeightAdjuster 1
19 WE124-4070212 MotorAssembly 1 52 WE124-301070861 SafetyCover 1
20 WE124-301070572 MotorFan 1 53 WE124-103030126 Blade33cm 1
21 WE124-103070119 Pulley 1 54 WE124-104040205 BladeBolt 1
22 WE124-301070860 DustCap 1 55 WE124-301070856 HousingInsert 1
23 WE124-104020020 Locknut 1 56 WE124-104050028 ShaftRing 2
24 WE124-103050243 Bearing 1 57 WE124-103050260 RotationShaft 1
25 WE124-301070575A MotorBracket 1 58 WE124-103060300 TorsionalSpring 1
26 WE124-103060208 Spring 1 59 WE124-301070916 GrassFlap 1
27 WE124-105990189 BrakeBlock 1 60 WE124-103020124 CollectorFrame 1
28 WE124-104030378 ST4.8×18Screw 5 61 WE124-301070917 CollectorTop 1
29 WE124-104030162 ST4.2X18Screw 7 62 WE124-301070580P CollectorCarryHandle 1
30 WE124-103050244 Bearing 1 63 WE124-301062859 FullIndicatorFlap 1
31 WE124-104030042 ST3*8Screw 4 64 WE124-105011066 BottomCollector 1
32 WE124-103040115 BrakeBlock 1 65 WE124-104030136 ST4.2x15Screw 19
33 WE124-301070855 PulleyAssembly&Axle 1    
PARTS DIAGRAM
INSTRUCTION MANUAL
WEER33 Instruction Manual.indd 19 20/10/2016 14:11
