COMPONENTS
1
Handle
Switch Box
2
Trigger
Electric Cable Retainer
3 Safety Button 9 Grassbox Full Indicator
4 Electric Cable 10 Grassbox
5 Electric Cable Clips 11 Rear Wheel
6 Single Height Adjuster 12 Front Wheel
Carefully remove the machine from its packaging and check that you have all the components.
If parts are missing or damaged, please contact us:
Telephone: 01793 333212
(Mon to Fri 8.00am to 5.30pm excl. Bank Holidays)
Email: customerservice@webbgardenpower.co.uk
CONTENTS
SPECIFICATION
COMPONENTS
SAFETY INSTRUCTIONS
ASSEMBLY
OPERATION
MAINTENANCE
STORAGE
TROUBLE SHOOTING
PARTS DIAGRAM & LIST
WARRANTY
DECLARATION OF CONFORMITY
SPECIFICATION
Model WEER33
Product No. 1938122001
Motor Rated Power 1300W
Motor Rated Voltage 230-240V ~50Hz
No Load Speed 3600rpm
Cutting Width 33cm
Height of Cut 25-65mm
Height Adjustments 5
Grassbox Capacity 35L
Sound Pressure Level 76.8db(A)
Guaranteed Sound Power Level 89dB(A)
Vibration 3.47m/s
2
Insulation
Double Insulated IPX4
Weight N.W 8.8kg G.W 10.5kg
INSTRUCTION MANUAL
WEER33 Instruction Manual.indd 3 20/10/2016 14:11
