ASSEMBLY
Remove the machine and contents from the carton. Be sure the carton is empty before discarding.
If you require any assistance with regards to the contents of the lawnmower contact us:
Tel: 01793 333212 - Mon – Fri 8.30am – 5.00pm (excl. Bank Holidays)
Email: customerservice@webblawnmowers.co.uk
MACHINE
FITTING D-HANDLE
1. Place top handle onto drivesha.
2. Posion lower handle, beneath the top handle in a comfortable operang posion
3. Tighten the four fixing screws.
FITTING THE
HARNESS
1. Place the clasp of the harness, through the Harness Eyelet located on the drivesha
2. Adjust the Harness to ensure it is comfortable, but ght enough to allow you to operate the machine
appropriately.
JOINING ATTACHMENT TO THE POWER UNIT
1. Unghten the hand-wheel, located on the coupler.
2. Line up the aachment sha with the coupler and insert, pulling the locking pin on the coupler out to
house the aachment.
3. When fully housed, secure by ghtening the h
and-wheel.
HEDGE TRIMMER
ADJUSTING THE CUTTING HEAD ANGLE (Fig 3)
1. Stop the engine
2. Turn the clamp lever an-clockwise to loosen
3. Adjust the blade to the required angle, by moving the clamp level up or down the angle adjuster.
4. Turn the clamp lever clockwise to ghten.
