LINE TRIMMER & BRUSHCUTTER
FITTING GUARD/SHIELD
1. Install the safety cover onto the sha with the safety cover bracket.
2. Align the four screws of the cover with the safety cover bracket
3. Tighten the screws aer seng the safety cover bracket at the appropriate posion.
LINE TRIMMER
FITTING NYLON LINE CUTTING HEAD
1. Align hole in adapter plate with hole in the sha and install Allen Key.
2. Thread cuer head onto sha (turning it an-clockwise) unl it is ght. Remove locking tool.
BRUSHCUTTER
FITTING THE METAL BLADE
1. Install holder A, the blade , holder B, teeth washer, in this order
2. Then clamp with the le-hand thread nut.
3. Align hole of gear case and holder A, and insert Allen Key.
4. Rotate blade-fastening nut with spanner in clockwise direcon un
l securely ghtened.
5. Install the Pin 2×16 and split legs to secure.
WARNING
EXCESSIVE VIBRATION OF THE BLADE INDICATES IT HAS NOT BEEN INSTALLED CORRECTLY.
STOP THE ENGINE IMMEDIATELY, CHECK THE BLADE INSTALLATION AND RE-INSTALL CORRECTLY. AN
INCORRECTLY INSTALLED BLADE CAN CAUSE INJURY.
