Weber mt CF 2 - 3.3.2 Cleaning;Replacing the Air Filter Cartridge

3.3.2 Cleaning/Replacing the Air Filter
Cartridge
Figure 33
Figure 32
1
2
2
1
24 CF-2
1
2
3.3.2.1 CF 2 Robin
- Remove the wing nut (32/1) and the air filter cover (32/2).
- Pull out the air filter element (33/2) and the pre-cleaner
(33/3).
- Wash the pre-cleaner (33/3) in benzine and let it dry.
Environment Hazard!
Dispose of the washing solution in an environmentally-
friendly manner.
- Knock or blow the air filter element (33/1) clean.
Caution!
If this procedure does not provide a sufficient cleaning
(e. g. because of humid or oily dirt), a new filter
element must be used.
- Insert the filter again.
- Fit the air filter cover (33/2) with the wing nut (32/1).
