3.3.2.2 CF-2 Honda
- Remove the wing nut (34/2) and the air filter cover (34/1).
- Pull out the air filter element (35/1) and remove the foam pre-cleaner (35/
2).
- Wash out the foam pre-cleaner (35/2) in benzine and let it dry.
Environment Hazard!
Dispose of the washing solution in an environmentally-friendly
manner.
- Knock or blow the air filter element (35/1) clean.
Caution!
If this procedure does not provide a sufficient cleaning (e.g. because
of humid or oily dirt), a new filter element must be used.
- Insert the filter (36/1) again and fasten it with the thumb nut (36/2).
-Put the cover (34/1) on the air filter and fasten it with the thumb nut (34/
2).
2
2
2
2
1
Figure 34
Figure 35
Figure 36
1
1
CF-2 25
