8 CF-2
1.3 Specifications
CF 2 Robin CF 2 Honda
Weight
Operating weight CECE in kg 80 80
Dimensions
Overall length (in mm) 1030 1030
Overall width (in mm) 440 440
Height with handle folded down (in mm) 980 980
Base plate length, contact area (in mm) 345 345
Trans port dimens ions Lx W x H (in mm) 345x440 345x 440
Propulsion
Engine Manufacturer Robin Honda
Type EX 17 D GX 160
Max. output acc. to DIN 70020(in kW (HP)) 4.2 (5,7) at 4000 rpm 4.0 (5.5) at 3600 rpm
Type of combus tion 4-s trok e, gasoline 4-s troke, gasoline
Max. operating speed 3600 3600
Travelling speed forward (acc. to soil, in m/min) 25 25
Gradeability (acc. to soil, in %) 30 30
Depth compaction (in cm) 20 - 25 20-25
Performance (in m²/h) 528 528
Vibration
System one-shaft vibrator one-shaft vibrator
Mode of driving mechanical mechanical
Frequency (in Hz) 98 98
Centrifugal force (in kN) 12 12
