Weber mt CF 2 - 3.3.3 Cleaning;Replacing the Fuel Filter

Figure 37
1
Figure 38
3.3.3 Cleaning/Replacing the Fuel Filter
-Put the soil compactor out of operation as described
in paragraph 2.7.
3.3.3.1 CF 2 Robin
-Take the cover off the tank (37/2).
- Take the strainer (37/1) out of the tank (37/2) and
clean it.
- Reinstall in inverse order.
Environment Hazard!
Immediately wipe up any escaping fuel,
dispose of the fuel-soaked cloth in an
environmentally-friendly manner.
- Undo the sight glass (38/1) beneath the fuel stop
cock (38/2).
- Take the strainer out of the sight glass (38/1) and
clean it.
- Reinstall in inverse order and check for tightness.
1
26 CF-2
