Weber mt CR 1 - Technical Data

CR 1_CR 2R 11
CR 1 R CR 2 R
Noise emissions in accordance with 2000/14/EC
100
108
100
108
Sound pressure level L
PA
ascertained in accordance
with EN 500, in dB (A)
Sound power level L
WA
ascertained in accordance
with EN ISO 3744 and EN 500, in dB (A)
Vibration values
4,7 5,6
Root-mean-square acceleration value for
hand-arm vibration ascertained in accordance
with EN 500 in m/s²
In accordance with directive 2006/42/EC,
complying with the vibration values is the
owner’s responsibility.
CR 1 R CR 2 R
Weight
Operating weight CECE in kg (basic device)
104 132
Dimensions
Overall length (in mm)
1044 1079
Overall width (in mm)
400 450
Height with folded manual guidance rod (in mm) 1006 1061
Base plate length (base in mm)
300 320
Pressure surface (in mm)
400x300 450x320
Drive
Engine manufacturer
Robin-Subaru Robin-Subaru
Type
EX 17 EX 17
Performance at operating speed in accordance
with ISO 3046-1 (kW)
4.2 4.2
Combustion process 4-stroke gasoline 4-stroke gasoline
Operating speed (1/min) 3350 3350
Operating speed (ground-dependent in m/min) 20 14
Incline capacity (ground-dependent in %) 30 30
Area capacity (in m²/h) 480 378
Vibration
System Two-wave vibrator Two-wave vibrator
Drive concept Mechanical Mechanical
Frequency (in Hz) 100 100
Centrifugal force (in kN) 20 25
Technical data
