Transport
Fit the crane hook into the protective frame (1) and lift the
machine onto the means of transport selected.
Only use lifting machines with a minimum bearing
capacity of 200 kg.
Arrest the manual guidance rod (1) with the spring bolt (2).
When transporting the soil compactor on a vehicle,
secure it with suitable restraints.
Do not step under suspended loads.
Activities prior to starting work
Checking the engine oil level
Pull the oil dip stick (1) out of the crankcase.
The correct oil level is between the min. and max. marks.
Check the fuel level
Open and remove the gas cap (1), check the level, if
necessary top off to the lower edge of the ller neck with
clean fuel in accordance with the specication.
For work at the fuel system, have a suitable re-
extinguishing agent at the ready.
Fire, naked light, and smoking is forbidden!
Max.
Min.
