CR 1_CR 2R 19
1
1
1
Changing the oil in the exciter
Remove the oil drain screw (1) and drain oil.
To ll – tilt the machine slightly and ll with fresh oil through
the drain opening in accordance with the ll level table.
Checking the V-belt
Remove the V-belt guard (1).
Check the V-belt (1) for cracks, damaged anks, and wear.
If there is excessive wear – replace the V-belt as specied in
the repair manual.
Select a collection vessel that is large enough to prevent
oil from spilling on the ground. Dispose of waste oil in an
environmentally friendly manner (regulation on waste oils).
Wipe up / off oil slick and oil residue and dispose of
fuel-soaked cleaning cloths in an environmentally re-
sponsible manner.
