7
Step 1
Check package contents
Cooking box
(assembly)
Lid
(assembly)
Hose
Bottom tray
Cooking grates (2)
Flavorizer Bars (5)
Control panel
Assembly
Tools needed
Hammer
7/16 and 3/4 inch open-end or an adjustable wrench
Pliers
Block of wood
Phillips screwdriver
Supplies needed
You will need a soap and water solution to check for gas
leaks. (See Step "Check for gas leaks.")
Note - The hardware size of nuts, bolts and screws is given.
For example "1/4-20 x 2 inch bolt" means a bolt 1/4 inch in
diameter with 20 threads to the inch, 2 inches long. On a
small screw for example, "6-32 x 1/2 inch screw" means a
number 6 screw, with 32 threads to the inch, 1/2 inch long.
While we give much attention to our products,
unfortunately an occasional error may occur. If a part is
missing, do not go back to the store. Call the W eber
Customer Service Center toll free 1-800-446-1071 to
receive immediate assistance. Have your owner ’s
manual and serial number of the barbecue available
for reference.
