8
Getting Started
Prepare to Install the LPG Cylinder
The gas hose must be secured to the side panel with
the supplied hose retention bracket.
1) Open cabinet doors.
2) Slide hose retention bracket (A) along hose to align
with mounting tab inside left panel. Secure with one
Phillips head screw.
LPG Cylinder Installation
1) Lift and place the cylinder into the cylinder holder
(B) on the bottom panel. The base of the cylinder
must fit within the cylinder holder.
2) Turn the cylinder so the valve opening faces the
front of the barbecue.
3) Secure the cylinder with the cylinder strap (C).
4) Connect the regulator to the LPG cylinder. Refer to
“CONNECT THE REGULATOR TO THE CYLINDER.”
m WARNING: The hose must be secured to the
side panel with the hose retention bracket.
Failure to do so could cause damage to the
hose resulting in a fire or explosion, which
can cause serious bodily injury or death, and
damage to property.
Maximum LPG cylinder
capacity INSIDE cabinet
is13kg.
The length of hose must
notexceed 1.5 metres.
