Weber Genesis Silver C User Manual

B-2
(1)
Complete frame assembly
You will need: partial frame assembly, two frame
connectors, four 2 inch bolts, four nylon
washers and a 7/16 inch or adjustable wrench.
Hold one frame connector between the caster frame
and wheel frame. Add the nylon washer to the bolt.
Insert the bolt through the frame and screw into frame
connector. Tighten bolt with wrench.
Repeat procedure with the other frame connector.
Continue frame assembly
You will need: caster frame and wheel frame.
Place the caster frame onto the tabs of the left frame,
so that the swing table locking bracket (1) is to the rear.
Place the wheel frame onto the tabs of the right frame,
so that the swing table locking bracket is to the rear
(2). The leg tabs must be on the inside of the frames.
(1)
Add front panel
You will need: frame assembly, front panel, two 1/2
inch bolts, two nylon washers, and a 7/16 or adjustable
spanner.
Place the front panel with the matchlight hole(1) down
and to your right against the inside frame assembly as
shown in illustration.
Add washer to bolt. Insert bolt through the front panel
and into the frame. Insert bolt on other end through the
front panel and the frame. Tighten bolts.
Add back panel
You will need: frame assembly, back panel, two 1/2
inch bolts, two nylon washers, and a 7/16 or adjustable
spanner.
Place the back panel against the inside frame
assembly as shown in illustration.
Add washer to bolt. Insert bolt through the back panel
and into the frame. Insert bolt on other end through the
back panel and the frame. Tighten bolts.

Weber Genesis Silver C Specifications

General

Grill Type	Gas
Main Burners	3
Dimensions	64 H x 60 W x 30 D (inches)
Fuel Type	Liquid Propane
Ignition System	Electronic
Ignition	Electronic
Material	Porcelain-enameled, cast-iron cooking grates
