Weber Genesis Silver C User Manual

C-1
Installing Features
Install the right trim piece with tool holders
You will need: Right trim piece with tool holders
Push the Right trim piece into the frame as shown(1),
making sure that the tabs on the underside of the trim
piece are snapped into the slots in the frame.(2)
(1)
(2)
C003.e
Install the left end trim piece and swing-up work
surface
You will need: End trim piece, swing-up work surface,
swing-up work surface rod, two 1/2 inch bolts, two
nylon washers and a wrench
1.) Start the left end trim piece into the frame as
shown, do not push the trim piece in all of the
way and do not add bolts yet.
2.) Slide the swing-up work surface rod through the
holes at the top of the swing-up work surface.

Weber Genesis Silver C Specifications

General

Grill Type	Gas
Main Burners	3
Dimensions	64 H x 60 W x 30 D (inches)
Fuel Type	Liquid Propane
Ignition System	Electronic
Ignition	Electronic
Material	Porcelain-enameled, cast-iron cooking grates
