B-6
(1)
(2)
Install Lid
You will need: lid, two hair pin cotters(1) and two hinge
pins(2).
Place lid on top of the cooking box. Align the hinges at
the rear of the barbecue. Insert hinge pins through the
hinges from the outside. Insert hair pin cotters into the
small holes in the hinge pins.
Install control panel and burner control knobs
You will need: control panel, two Phillips screws/
washers, a Phillips screwdriver, and burner control
knobs.
1)
Set the control panel in place over both frame
braces. Hold the Crossover Ignition button up while
setting the control panel in place.
2)
Line up the holes in the control panel with the
holes in the white plastic plugs in the frame brace.
Insert screws and tighten with a Phillips
screwdriver until snug. Do not overtighten.
3)
Push each of the burner control knobs onto their
valve.
(1)
(2)
(3)
