C-2
3.) Insert one end of the swing-up work surface rod
into the hole in the frame.
4.) While holding swing-up work surface in position,
insert the other end of the swing-up work surface
rod into the left end trim piece. Push the trim piece
into the frame.
5.) Add a washer to each bolt and insert it through the
hole in the frame and the hole in the trim piece on
both sides. Tighten with a wrench.
To raise swing-up work surface: Lift table all the way
up and slide it to the right, then lower table until you
feel it lock in the up position.
To lower swing-up work surface: Lift table up until it
disengages and slide it to the left. Then lower it all the
way down so that the locking pin on the right side of
the table fits into the locking bracket on the leg, which
will secure the table in the down position.
Do not use the work surface as a cutting board.
