Weber Genesis Silver C User Manual

B-4
(2)
(1)
(1)
(1) (2)
Add fuel gauge
You will need: fuel gauge, two wing nuts and two nylon
washers.
1) Slip the bolts on the back of the fuel gauge
through the two small holes in the cylinder panel.
2) Add washers to the bolts, then wing nuts, and
tighten with your fingers.
Install cylinder panel
You will need: Cylinder panel, two 1 3/4inch bolts, two
nylon cylinder glides, two nylon washers a 7/16 inch or
adjustable wrench and pliers.
Insert the cylinder panel tabs(1) into the slots in the
frame brace(2).
Slide the cylinder panel up until notch at bottom of
panel fits over the cross brace(1). Add nylon washer to
bolt and insert through the hole in the wheel frame at
the bottom right of the cylinder panel, make sure that
the bolt slips through the hole in the cylinder panel.
Add nylon cylinder glide to bolt end and tighten bolt
with the wrench, while holding the cylinder glide with
the pliers. Repeat procedure with the hole on the
bottom left side of the cylinder panel.
(1)
(2)
Install manifold brackets
The manifold brackets(2) are already in place on the
manifold between the valves.
Place your hand underneath the manifold. Lift the
manifold and cooking box slightly and hook the
manifold bracket(2) onto the frame brace(1).

Weber Genesis Silver C Specifications

General

Grill Type	Gas
Main Burners	3
Dimensions	64 H x 60 W x 30 D (inches)
Fuel Type	Liquid Propane
Ignition System	Electronic
Ignition	Electronic
Material	Porcelain-enameled, cast-iron cooking grates
