11
Step 2 (cont.)
- Once the One Touch Handle is through the handle
slot of the Ash Catcher Ring, tilt the ring back down
and position the locking clips over the couplings on
the bottom of the bowl.
Once the the locking clips are in position over the
couplings push the ring straight down until the clips snap
into position as shown in figure 2b.
Figure 2b
Locking Clip
Coupling
î Caution: Make sure all Locking Clips are fully
engaged in each coupling as shown below.
To Next Page
