7
1. 1/4-20 x 5/8 inch truss head screw
2. Nylon damper handle
3. Lid damper
4. 1/4 inch aluminum washer (9)
5. 1/4-20 acorn nut (4)
6. Lid assembly
7. 22 inch hinged cooking grate
8. Char-Baskets Fuel Holders (2)
9. Charcoal grate
10.H-drive
11-13. Damper blades
14.1/4-20 x 1 3/4 inch bolt (8)
15.1/4 inch nylon washers (16)
16.Lid holder support strap
17.Lid holder lower support
18.1/4-20 hex keps nut (5)
19.Lid holder wire
20. Lid roller
21.Bowl
22.H-washer
23.Control rod
24.Ash catcher ring assembly
25.Ash catcher and handle
26.1/4-20 x 1/2 inch bolt (4)
27.Wheel frame
28.Axle
29.Wheels (2)
30.Wheel hub caps (2)
31.#8-18 x 5/8 inch screw (3)
32.Nylon lid handle (top)
33.Nylon lid handle (bottom)
34. Thermometer mount assembly
35.Thermometer
36.CharBin Storage Container
37.Bowl panel
38.Control panel
39.Burner assembly
40.Orifice clip
41.Hose and regulator assembly
42.CharBin lid handle
43.CharBin lid
44.Hinge rod
45.Tool holders (3)
46.Igniter and lock nut
47.Top frame
48.Tubing plugs (4)
49.Cooking grate holder
50.Front panel assembly
51.Caster frame
52.Tank holder
53.Tank panel
54.Bottom connector (2)
55.Caster inserts (2)
56.Casters (2)
57.Bottom rack
58.Match holder/burner cleaning tool
59.5 lb LP tank
60.Filler adapter
îWARNING:
Use only Weber factory authorized parts.
The use of any part that is not factory
authorized can be dangerous. This will also
void your warranty.
Parts List
All items are single quantities unless otherwise specified.
Parts can be ordered directly from Weber-Stephen
Products Company by phone or mail.
Note - Do not return parts to Weber-Stephen Products
Co. without first contacting the Customer service Center
by phone or mail. Returning the part may not be
necessary.
