6
VEHICLE SIGNAL BOOSTER DRIVE X
ENGLISH
______
Step 4: Connect Power
Supply To Booster
Connect the power supply cord to the end of the Drive X
labeled “Power.”
NOTE: Do NOT connect the power to the Signal Booster until you have
connected both the Inside and Outside Antennas.
Power Supply

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the weBoost DRIVE X and is the answer not in the manual?

weBoost DRIVE X Specifications

General IconGeneral
Max Gain50 dB
Impedance50 Ohms
ConnectorsSMA Female
Power Supply12V DC
Cable Length12 feet
Downlink698-960 MHz, 1710-2700 MHz
CompatibilityAll US carriers
Dimensions (Antenna)6.5 x 4.5 x 1.5 inches
Weight (Antenna)1.5 lbs
