WeCo Srl Italy www.wecobatteries.com 4K4LT V1.00 24/01/2023
Wall installation procedure
Step 1: Install the fixing screws on the appropriate wall height.
When installing screws, please check the size of the wall plug, WeCo provides 4x φ10*60mm, but you may need a different size or type depending
on the actual installation surface.
Step 2: Make sure the mounting screws are securely attached to the wall.
When the battery bracket has been secured, please work with a partner and install the battery on the wall bracket, in order to avoid personal
injury or damage to the product.
Step 3: Attach the support plate to the wall Step 4: Attach the battery module to the wall bracket.
Slide the foot loosening the screws
that support it, until the battery is
perfectly coplanar with the wall.
