Weco 4K4LT - Internal Layout

27
WeCo Srl Italy www.wecobatteries.com 4K4LT V1.00 24/01/2023
Internal Layout.
(Do not open the lid so as not to lose the right to the warranty)
Module 8S A+CCS Board
Module 8S B+CCS Board
FUSE CCN 150A
INTEGRATED BMS + MOSFET
