WECO 5K3-XP-EMEA

3.3 HV BOX Overview

Wi-Fi ANTENNA

Optional Accessory

FRONT PLATE

HV CONNECTION HUB

RUN LED

GREE

POWER LED

RED

MAIN BREAKER

750/1000Vdc 125A

FIXING BRAKET
