English
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P275
(*)
DO1 Function 0 = Not Used
1 = F* ≥ Fx
2 = F ≥ Fx
3 = F ≤ Fx
4 = F = F*
5 = Not Used
6 = Is >Ix
7 = Is <Ix
8 = Torque >Tx
9 = Torque <Tx
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No F070
15 = Not Used
16 = No F021/F022
17 = Not Used
18 = No F072
19 = 4-20 mA OK
20 = P695 Value
21 = Forward
22 to 23 = Not Used
24 = Ride-Through
25 = Pre-Charge OK
26 = Fault
27 = Not Used
28 = SoftPLC
29 to 34 = Not Used
35 = No Alarm
36 = Without fault and alarm
37 = Application Function 1
38 = Application Function 2
39 = Application Function 3
40 = Application Function 4
41 = Application Function 5
42 = Application Function 6
43 = Application Function 7
44 = Application Function 8
45 = Fire Mode ON
46 = Low Level of Process Variable
47 = High Level of Process Variable
13
P276
(*)
DO2 Function See options in P275 0
P277
(*)
DO3 Function See options in P275 0
P281
(*)
Fx Frequency 0.0 to 400.0 Hz 3.0 Hz
P282
(*)
Fx Hysteresis 0.0 to 15.0 Hz 0.5 Hz
P290
(*)
Ix Current 0.0 to 10.0 A 1,0 x I
nom
P293
(*)
Tx Torque 0 to 200 % 100 %
P295 Inverter Rated Current 1.6 to 15.2 A According to the
Inverter Model
ro
P296 Line Rated Voltage 0 = Reserved
1 = 110 - 127 Vac
2 = 200 - 240 Vac
According to the
Inverter Model
ro
P297 Switching Frequency 2.5 to 15.0 kHz 5.0 kHz cfg, V/f, VVW
P299 DC Braking Start Time 0.0 to 15.0 s 0.0 s V/f, VVW
P300 DC Braking Stop Time 0.0 to 15.0 s 0.0 s V/f, VVW
P301 DC Braking Frequency 0.0 to 15.0 Hz 3.0 Hz V/f, VVW
P302 DC Braking Current 0.0 to 100.0 % 20.0 % V/f, VVW
P303 Skip Frequency 1 0.0 to 400.0 Hz 0.0 Hz V/f, VVW
P304 Skip Frequency 2 0.0 to 400.0 Hz 0.0 Hz V/f, VVW
P306 Skip Band 0.0 to 25.0 Hz 0.0 Hz V/f, VVW
P308 Serial Address 1 to 247 1 cfg
P310 Serial Baud Rate 0 = 9600 bits/s
1 = 19200 bits/s
2 = 38400 bits/s
1 cfg
P311 Serial Bytes Config. 0 = 8 bits, no, 1
1 = 8 bits, even,1
2 = 8 bits, odd, 1
3 = 8 bits, no, 2
4 = 8 bits, even,2
5 = 8 bits, odd, 2
1 cfg
CFW100 | 13
