QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P312 Serial Protocol 0 to 1 = Reserved
2 = Modbus RTU Slave
3 to 4 = Reserved
5 = ModBus RTU Master
2 cfg
P313 Action for Communic. Error 0 = Inactive
1 = Ramp Stop
2 = General Disable
3 = Go to LOC
4 = LOC Keep Enab.
5 = Cause Fault
1
P314 Serial Watchdog 0.0 to 999.0 s 0.0 s cfg
P316 Serial Interf. Status 0 = Inactive
1 = Active
2 = Watchdog Error
ro
P320 Flying Start / Ride-Through 0 = Inactive
1 = Flying Start
2 = FS / RT
3 = Ride-Through
0 cfg
P331 Voltage Ramp for FS and RT 0.2 to 60.0 s 2.0 s
P332 Dead Time 0.1 to 10.0 s 1.0 s
P340 Auto-Reset Time 0 to 255 s 0 s
P352 Fan Control Config. 0 = OFF
1 = ON
2 = CT
2 cfg
P375
(*)
NTC Temperature 0 to 200 ºC ro
P397 Control Config 0 to F (hexa)
Bit 0 = Slip Compens. Regen.
Bit 1 = Reserved
Bit 2 = Is Stabilization
Bit 3 = P297 reduction in A050
1 cfg
P399 Motor Rated Efficiency 50.0 to 99.9 % According to the
Inverter Model
cfg, VVW
P400 Motor Rated Voltage 0 to 240 V 220 V cfg, VVW
P401 Motor Rated Current 0.0 to 10.0 A 1,0 x I
nom
cfg, VVW
P402 Motor Rated Speed 0 to 24000 rpm 1720 rpm cfg, VVW
P403 Motor Rated Frequency 0 to 400 Hz 60 Hz cfg, VVW
P404 Motor Rated Power 0 = 0.16 HP (0.12 kW)
1 = 0.25 HP (0.18 kW)
2 = 0.33 HP (0.25 kW)
3 = 0.50 HP (0.37 kW)
4 = 0.75 HP (0.55 kW)
5 = 1.00 HP (0.75 kW)
2 cfg, VVW
P407 Motor Rated Power Factor 0.50 to 0.99 According to the
Inverter Model
cfg, VVW
P408 Run Self-Tuning 0 = No
1 = Yes
0 cfg, VVW
P409 Stator Resistance 0.01 to 99.99 According to the
Inverter Model
cfg, VVW
P510 SoftPLC Eng. Unit See options in P209 0
P511 SoftPLC Indication Form See options in P210 1
P580 Fire Mode Config 0 = Inactive
1 = Active
2 = Active / P134
3 = Reserved
4 = Active / General Disable
0 cfg
P582 Fire Mode Auto-reset Adjustable 0 = Limited
1 = Unlimited
0 cfg
P588 EOC Maximum Torque 0 to 85 % 0 % cfg
P589 EOC Minimum Voltage 40 to 80 % 40 % cfg
P590 EOC Minimum Frequency 12.0 to 400.0 Hz 20.0 Hz cfg
P591 EOC Hysteresis 0 to 30 % 10 % cfg
P613 Main SW Revision -9999 to 9999 ro
14 | CFW100
