QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P914 SoftPLC Parameter 5 -9999 to 9999 0
P915 SoftPLC Parameter 6 -9999 to 9999 0
P916 SoftPLC Parameter 7 -9999 to 9999 0
P917 SoftPLC Parameter 8 -9999 to 9999 0
P918 SoftPLC Parameter 9 -9999 to 9999 0
P919 SoftPLC Parameter 10 -9999 to 9999 0
P920 SoftPLC Parameter 11 -9999 to 9999 0
P921 SoftPLC Parameter 12 -9999 to 9999 0
P922 SoftPLC Parameter 13 -9999 to 9999 0
P923 SoftPLC Parameter 14 -9999 to 9999 0
P924 SoftPLC Parameter 15 -9999 to 9999 0
P925 SoftPLC Parameter 16 -9999 to 9999 0
P926 SoftPLC Parameter 17 -9999 to 9999 0
P927 SoftPLC Parameter 18 -9999 to 9999 0
P928 SoftPLC Parameter 19 -9999 to 9999 0
P929 SoftPLC Parameter 20 -9999 to 9999 0
P930 SoftPLC Parameter 21 -9999 to 9999 0
P931 SoftPLC Parameter 22 -9999 to 9999 0
P932 SoftPLC Parameter 23 -9999 to 9999 0
P933 SoftPLC Parameter 24 -9999 to 9999 0
P934 SoftPLC Parameter 25 -9999 to 9999 0
P935 SoftPLC Parameter 26 -9999 to 9999 0
P936 SoftPLC Parameter 27 -9999 to 9999 0
P937 SoftPLC Parameter 28 -9999 to 9999 0
P938 SoftPLC Parameter 29 -9999 to 9999 0
P939 SoftPLC Parameter 30 -9999 to 9999 0
P940 SoftPLC Parameter 31 -9999 to 9999 0
P941 SoftPLC Parameter 32 -9999 to 9999 0
P942 SoftPLC Parameter 33 -9999 to 9999 0
P943 SoftPLC Parameter 34 -9999 to 9999 0
P944 SoftPLC Parameter 35 -9999 to 9999 0
P945 SoftPLC Parameter 36 -9999 to 9999 0
P946 SoftPLC Parameter 37 -9999 to 9999 0
P947 SoftPLC Parameter 38 -9999 to 9999 0
P948 SoftPLC Parameter 39 -9999 to 9999 0
P949 SoftPLC Parameter 40 -9999 to 9999 0
P950 SoftPLC Parameter 41 -9999 to 9999 0
P951 SoftPLC Parameter 42 -9999 to 9999 0
P952 SoftPLC Parameter 43 -9999 to 9999 0
P953 SoftPLC Parameter 44 -9999 to 9999 0
P954 SoftPLC Parameter 45 -9999 to 9999 0
P955 SoftPLC Parameter 46 -9999 to 9999 0
P956 SoftPLC Parameter 47 -9999 to 9999 0
P957 SoftPLC Parameter 48 -9999 to 9999 0
P958 SoftPLC Parameter 49 -9999 to 9999 0
P959 SoftPLC Parameter 50 -9999 to 9999 0
SoftPLC Parameter Configuration for PID Controller Application (P903 = 1)
Param. Description Adjustable Range Factory Setting Prop.
P910 PID Controller Application Version 0.00 to 90.00 ro
P911 Control Setpoint -99.99 to 99.99 2.00
P912 Control Setpoint 1 -99.99 to 99.99 2.00
P913 Control Setpoint 2 -99.99 to 99.99 2.30
P914 Control Setpoint 3 -99.99 to 99.99 1.80
P915 Control Setpoint 4 -99.99 to 99.99 1.60
P916 Control Process Variable -99.99 to 99.99 ro
P917 PID Controller Output 0.0 to 100.0 % ro
P918 PID Controller Setpoint in Manual
Mode
0.0 to 400.0Hz 0.0Hz
