QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P705
(*)
CAN Controller Status 0 = Disabled
1 = Auto-baud
2 = CAN Active
3 = Warning
4 = Error Passive
5 = Bus Off
6 = No Bus Power
ro
P706
(*)
RX CAN Telegrams 0 to 9999 ro
P707
(*)
TX CAN Telegrams 0 to 9999 ro
P708
(*)
Bus Off Counter 0 to 9999 ro
P709
(*)
CAN Lost Messages 0 to 9999 ro
P710
(*)
DeviceNet I/O instances 0 = ODVA Basic 2W
1 = ODVA Extend 2W
2 = Manuf.Spec.2W
3 = Manuf.Spec.3W
4 = Manuf.Spec.4W
5 = Manuf.Spec.5W
6 = Manuf.Spec.6W
0
P711
(*)
DeviceNet Read Word #3 0 to 1199 0
P712
(*)
DeviceNet Read Word #4 0 to 1199 0
P713
(*)
DeviceNet Read Word #5 0 to 1199 0
P714
(*)
DeviceNet Read Word #6 0 to 1199 0
P715
(*)
DeviceNet Write Word #3 0 to 1199 0
P716
(*)
DeviceNet Write Word #4 0 to 1199 0
P717
(*)
DeviceNet Write Word #5 0 to 1199 0
P718
(*)
DeviceNet Write Word #6 0 to 1199 0
P719
(*)
DeviceNet Network Status 0 = Offline
1 = OnLine, NotConn
2 = OnLine, Connect.
3 = Connection Timed out
4 = Link Failure
5 = Auto-Baud
ro
P720
(*)
DeviceNet Master Status 0 = Run
1 = Idle
ro
P721
(*)
CANopen Comm. Status 0 = Disabled
1 = Reserved
2 = Communic. Enabled
3 = Error Ctrl. Enable
4 = Guarding Error
5 = Heartbeat Error
ro
P722
(*)
CANopen Node Status 0 = Disabled
1 = Initialization
2 = Stopped
3 = Operational
4 = Preoperational
ro
P770
(*)
Blueooth Device Name 0 to 9999 Serial Number of the
Inverter
P771
(*)
Bluetooth Password PIN 0 to 9999 1234
P840
(*)
IR Control Command 0 to FFFF (hexa) ro
P842
(*)
Quick View 1 IR 0 to 959 2
P843
(*)
Quick View 2 IR 0 to 959 375
P900 SoftPLC Status 0 = No Application
1 = Installing Application
2 = Incompat. Application
3 = Application Stopped
4 = Application Running
ro
P901 SoftPLC Command 0 = Stop Application
1 = Run Application
0
P902 Scan Cycle Time 0.000 to 9.999 s ro
P903 SoftPLC Appl. 0 = User
1 = PID Controller
1 cfg
P904 Action for SoftPLC Application not
Running
0 = Disabled
1 = Cause Alarm (A708)
2 = Cause Fault (F709)
0
P910 SoftPLC Parameter 1 -9999 to 9999 0
P911 SoftPLC Parameter 2 -9999 to 9999 0
P912 SoftPLC Parameter 3 -9999 to 9999 0
P913 SoftPLC Parameter 4 -9999 to 9999 0
16 | CFW100
