QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P082 Third Fault on Fire Mode 0 to 999 ro
P100 Acceleration Time 0.1 to 999.9 s 5.0 s
P101 Deceleration Time 0.1 to 999.9 s 10.0 s
P102 Acceleration Time 2nd Ramp 0.1 to 999.9 s 5.0 s
P103 Deceleration Time 2nd Ramp 0.1 to 999.9 s 10.0 s
P104 Ramp S 0 = Inactive
1 = Active
0 cfg
P105 1st / 2nd Ramp Selection 0 = 1st Ramp
1 = 2nd Ramp
2 = DIx
3 = Serial/USB
4 = Reserved
5 = CO/DN
6 = SoftPLC
0
P106 Emer. R. Acceleration Time 0.1 to 999.9 s 5.0 s
P107 Emer. R. Time Deceleration 0.1 to 999.9 s 5.0 s
P120 Speed Ref. Backup 0 = Inactive
1 = Active
2 = Backup by P121
1
P121 Reference via HMI 0.0 to 400.0 Hz 3.0 Hz
P122 JOG Reference -400.0 to 400.0 Hz 5.0 Hz
P124 Multispeed Ref. 1 -400.0 to 400.0 Hz 3.0 Hz
P125 Multispeed Ref. 2 -400.0 to 400.0 Hz 10.0 (5.0) Hz
P126 Multispeed Ref. 3 -400.0 to 400.0 Hz 20.0 (10.0) Hz
P127 Multispeed Ref. 4 -400.0 to 400.0 Hz 30.0 (20.0) Hz
P128 Multispeed Ref. 5 -400.0 to 400.0 Hz 40.0 (30.0) Hz
P129 Multispeed Ref. 6 -400.0 to 400.0 Hz 50.0 (40.0) Hz
P130 Multispeed Ref. 7 -400.0 to 400.0 Hz 60.0 (50.0) Hz
P131 Multispeed Ref. 8 -400.0 to 400.0 Hz 66.0 (55.0) Hz
P133 Minimum Frequency 0.0 to 400.0 Hz 3.0 Hz
P134 Maximum Frequency 0.0 to 400.0 Hz 66.0 (55.0) Hz
P135 Maximum Output Current 0.0 to 40.0 A 1,5 x I
nom
V/f
P136 Manual Torque Boost 0.0 to 30.0 % According to the
Inverter Model
V/f
P137 Automatic Torque Boost 0.0 to 30.0 % 0.0 % V/f
P138 Slip Compensation -10.0 to 10.0 % 0.0 % V/f
P139 Output Current Filter 0.000 to 9.999 s 0.050 s V/f, VVW
P140 Slip Com. Filter 0.000 to 9.999 s 0.500 s VVW
P142 Maximum Output Voltage 0.0 to 100.0 % 100.0 % cfg, V/f
P143 Intermediate Output Voltage 0.0 to 100.0 % 50.0 % cfg, V/f
P145 Field Weakening Speed 0.0 to 400.0 Hz 60.0 (50.0) Hz cfg, V/f
P146 Intermediate Frequency 0.0 to 400.0 Hz 30.0 (25.0) Hz cfg, V/f
P149 DC Link Comp. Mode 0 = Inactive
1 = Standard
2 = Overmodulation
3 = Extended
1 cfg, V/f
P150 DC/LC Regul. Type 0 = hold_Ud and decel_LC
1 = accel_Ud and decel_LC
2 = hold_Ud and hold_LC
3 = accel_Ud and hold_LC
0 cfg, V/f, VVW
P151 DC Link Regul. Level 325 to 460 V 430 V (P296 = 1)
380 V (P296 = 2)
781 V (P296 = 4)
781 V (P296 = 5)
781 V (P296 = 6)
781 V (P296 = 7)
V/f, VVW
P156 Rated Speed Overload Current 0.1 to 40.0 A 1,2 x I
nom
P157 Overl.Curr.50 % Speed 0.1 to 40.0 A 1,2 x I
nom
P158 Overl.Curr.20 % Speed 0.1 to 40.0 A 1,2 x I
nom
P178 Rated Flux 50.0 to 150.0 % 100.0 % VVW
P200 Password 0 = Inactive
1 = Active
2 to 9999 = New Password
0 cfg
6 | CFW100
