QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P202 Type of Control 0 = V/f
1 = Quadratic V/f
2 to 4 = Not Used
5 = VVW
0 cfg
P204 Load/Save Parameters 0 to 4 = Not Used
5 = Load 60 Hz
6 = Load 50 Hz
7 = Load User
8 = Not Used
9 = Save User
10 = Not Used
11 = Load Default SoftPLC
12 to 13 = Reserved
0 cfg
P205 Main Display Parameter 0 to 999 2
P207 Bar Graph Parameter 0 to 999 3
P208 Ref. Scale Factor 1 to 9999 600
P209 Ref. Eng. Unit 0 to 1 = Without unit
2 = Volt (V)
3 = Hertz (Hz)
4 = Without unit
5 = Percent ( %)
6 = Without unit
7 = Rotation/min. (rpm)
3
P210 Ref. Decimal Point 0 = wxyz
1 = wxy.z
2 = wx.yz
3 = w.xyz
1
P213 Bar Scale Factor 1 to 9999 1,0 x I
nom
P219 Red. Switch. Freq. 0.0 to 15.0 Hz 5.0 Hz cfg
P220 LOC/REM Selection Source 0 = Always Local
1 = Always Remote
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (LOC)
6 = Serial/USB (REM)
7 to 8 = Not Used
9 = CO/DN (LOC)
10 = CO/DN (REM)
11 = SoftPLC
0 cfg
P221 LOC Reference Sel. 0 = HMI
1 = AI1
2 = Not Used
3 = Potentiometer
4 = FI
5 to 6 = Not Used
7 = E.P.
8 = Multispeed
9 = Serial/USB
10 = Not Used
11 = CO/DN
12 = SoftPLC
13 = Not Used
14 = AI1 >0
15 = Not Used
16 = Potentiometer >0
17 = FI >0
0 cfg
P222 REM Reference Selection See options in P221 2 cfg
P223 LOC FWD/REV Selection 0 = Foward
1 = Reverse
2 to 3 = Not Used
4 = DIx
5 = Serial/USB (FWD)
6 = Serial/USB (REV)
7 to 8 = Not Used
9 = CO/DN (FWD)
10 = CO/DN (REV)
11 = Not Used
12 = SoftPLC
0 cfg
P224 LOC Run/Stop Sel. 0 = HMI Keys
1 = DIx
2 = Serial/USB
3 = Not Used
4 = CO/DN
5 = SoftPLC
0 cfg
CFW100 | 7
