QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Description Adjustable Range Factory Setting Prop.
P225 LOC JOG Selection 0 = Disabled
1 = Not Used
2 = DIx
3 = Serial/USB
4 = Not Used
5 = CO/DN
6 = SoftPLC
1 cfg
P226 REM FWD/REV Selection See options in P223 4 cfg
P227 REM Run/Stop Selection See options in P224 1 cfg
P228 REM JOG Selection See options in P225 2 cfg
P229 Stop Mode Selection 0 = Ramp to Stop
1 = Coast to Stop
0 cfg
P230 Dead Zone (AIs and FI1 ) 0 = Inactive
1 = Active
0 cfg
P231
(*)
AI1 Signal Function 0 = Speed Ref.
1 to 3 = Not Used
4 = PTC
5 to 6 = Not Used
7 = PLC Use
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 = Control Setpoint
17 = Process Variable
0 cfg
P232
(*)
AI1 Input Gain 0.000 to 9.999 1.000
P233
(*)
AI1 Input Signal 0 = 0 to 10 V / 20 mA
1 = 4 to 20 mA
2 = 10 V / 20 mA to 0
3 = 20 to 4 mA
0
P234
(*)
AI1 Input Offset -100.0 to 100.0 % 0.0 %
P235
(*)
AI1 Input Filter 0.00 to 16.00 s 0.00 s
P241
(*)
Potentiometer Signal Function 0 = Speed Ref.
1 to 6 = Not Used
7 = SoftPLC
8 = Application Function 1
9 = Application Function 2
10 = Application Function 3
11 = Application Function 4
12 = Application Function 5
13 = Application Function 6
14 = Application Function 7
15 = Application Function 8
16 to 17 = Not Used
0 cfg
P242
(*)
Potentiometer Signal Gain 0.000 to 9.999 1.000
P244
(*)
Potentiometer Signal Offset -100.0 to 100.0 % 0.0 %
P245 Potentiometer and FI1 Filter 0.00 to 16.00 s 0.00 s
P246 FI1 Input Function 0 = Inactive
1 = Active in DI1
2 = Active in DI2
3 = Active in DI3
4 = Active in DI4
0 cfg
P247 FI1 Input Gain 0.000 to 9.999 1.000
P248 FI1 Minimum Input 1 to 3000 Hz 100 Hz
P249 FI1 Input Offset -100.0 to 100.0 % 0.0 %
P250 FI1 Maximum Input 1 to 3000 Hz 1000 Hz
8 | CFW100
