4 TECHNICAL SPECIFICATIONS
Table 4.1: CPW17 technical specifications
Electrical
Operating voltage – SELV / PELV + 24 V DC / AC ± 20 %
Reverse polarity protection Yes
Frequency operation 50 / 60 Hz
Power consumption ≤ 3 VA
Response time ≤ 10 ms
Controlled voltage at S0
AC 26 to 36 V DC
DC 20 to 30 V DC
Switching current, at 24 V DC
S1 30 mA
S2 30 mA
Logic of inputs
S1 PNP
S2 PNP
Working temperature -10 to +55 °C [+ 14 to + 131 ºF]
Storage temperature -40 to +70 °C [- 40 to + 158 ºF]
Output switching Force guided relays
Safety contacts 2 NO contacts (redundant)
Switching capability
DC13 24 V DC @ 3 A
AC15 250 V AC @ 3 A
Feedback Yes
Led indicators 2, relay status K1 and K2
Mechanical
Housing material Polyamide PA6
Dimensions 90 x 64 x 17.5 mm [3.54 x 2.51 x 0.68 in]
Weight ± 0.095 Kg
Connection type Screw terminals
Connection terminals
EUA 24 to 12 AWG
SI 0.5 to 2.5 mm
²
Ambient temperature -10 to +55 °C [+ 14 to + 131 ºF]
Degree of protection IP 20
Degree of contamination 2
Mounting DIN rail 35 mm or PLMP
Lifecycle
Electrical 2 E
6
Mechanical 1 E
7
Time life 20 Years
Safety
EN ISO 13849-1
CAT 4
PL e
IEC 61508 1-7
SIL 3
PFD 1 E
-5
AVG
SFF 98.67 %
IEC 62061
SIL CL 3
PFHd 1 E
-9
1/h
MTTFd > 100 years
