Dimensions
14 | CPW17
English
5 DIMENSIONS
17,5 [0.6 8 9]
90 [3.543]
90,55 [3.762]
64 [2.52]
60 [2.362]
96,4 [3.795]
Ø 3,1
[0.122]
Figure 5.1: Dimensions in millimeters [inches]
