Wega ALE Use And Maintenance Manual

TECHNICIANS' manual 91 of 100
14.3 DEBIT - CREDIT SYSTEM with
connection to the INTERFACE
14.3.1 Beverage selection code table
PIN RELAY GROUP DOSE BUTTON
1 Z11 1 1
2 Z12 1 2
3 Z13 1 3
4 Z14 1 4
5 Z15 1 5
6 Z16 1 6
7 Z21 2 1
8 Z22 2 2
9 Z23 2 3
10 Z24 2 4
11 Z25 2 5
12 Z26 2 6
13 Z31 3 1
14 Z32 3 2
15 Z33 3 3
16 Z34 3 4
17 Z35 3 5
18 Z36 3 6
19 Z41 4 1
20 Z42 4 2
21 Z43 4 3
22 Z44 4 4
23 Z45 4 5
24 Z46 4 6
25 ZT1 TEA
26 ZT2
27
28
29 Common HTW signals
30 Common HTW signals
31
32
33 ABHART*
34 GND*
