R660系列柴油机维修保养手册
Maintenace Manual For R660 Series Diesel Engine
清洗柴油滤清器
Clean fuel filter
滤清器需分解逐层清洗：
The fuel filter should be disassembled
and be cleaned according to the procedure
below:
－旋下紧固螺栓 3
- Screw off tighten nut 3;
－取下壳体 9
- Take off filter casing 9;
－旋下压紧螺母 4，取下芯盖 6
- Screw off compression nut 4, take off
cover 6;
—取出滤芯 7，
- Take out filter element 7;
－拆分开换滤芯，如有必要更换滤
纸。
- Disassemble filter element, replace filter
paper if necessory;
－浸入油液中用毛刷刷洗干净滤芯。
- Clean with brush in oil liquid;
－取下塞子，用压缩空气由内向外反
吹
- Remove plug and blow it with compressed
air from inside to outside; and
－重新进行安装
- Reassemble it.
