WEICHAI R6160 Series User Manual

--
R660系列柴油机维修保养手册
Maintenace Manual For R660 Series Diesel Engine
1.2 R6160Z 系列柴油机润滑系统流程图
Flowchart for lubricating system of R6160Z series diesel engine
摇臂Rocker arm
挺柱Tappet
凸轮轴Camshaft
机油泵Oil pump
机油冷却器Oil cooler
机油滤清器Oil filter
主油道Main oil passage
调节阀Adjusting valve
主轴承Main bearing
连杆轴承Connecting rod bearings
连杆轴承Connecting rod bearings
增压器轴承Turbocharger bearing
手压泵或电动预供油泵Hand pump or electric
oil pre-supply pump
传动齿轮Driving gear
传动轴齿轮Driving gear shaft
活塞销与轴套Piston pin and shaft casing
活塞与气缸配合面Matching surface of piston
and cylinder
机座Bed plate
