10
10. Attach an Arm Pad (6) to one of the Dip Arms
(5) with two M6 x 73mm Screws (18).
Repeat this step with the other Arm Pad (6).
9. Orient the Backrest (8) so that the name
“WEIDER” is at the top and the number “200” is
at the bottom. Attach the Backrest to the Top
C
rossbar (7) with four M6 x 16mm Screws (27)
and four M6 Washers (21).
11. Make sure that all parts have been properly tightened before the exercise rack is used. Note: Some
hardware may be left over after assembly is completed.
10
6
5
18
6
9
8
“200”
27
21
21
7
27
“WEIDER”
To Next Page
