5
PART IDENTIFICATION CHART
M6 Washer (21)
M8 Locknut (22)
M6 x 16mm Screw (27)
M6 x 73mm Screw (18)
M8 x 75mm Bolt (17)
M10 x 50mm Screw (19)
M8 x 77mm Bolt (28)
M8 Washer (23)
M8 x 68mm Carriage Bolt (20)
M8 x 68mm Bolt (24)
M10 Washer (26)
S
ee the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part from the PART LIST near the end of this manual. Note: If a part is not in the hard-
ware kit, check to see if it has been preattached. To avoid damaging parts, do not use power tools.
