11
9. Attach a Shroud Cover (23) to the Left and Right
Shrouds (21, 22) with two M6 x 28mm Bolts (94),
four M6 W
ashers (1
14), and two M6 Nylon
Locknuts (107).
Attach the Shroud Cover (23) to the
T
op Frame
(4) with four M4 x 16mm Self-tapping Screws
(110) and four M4 Washers (104).
See the inset drawing and attach the other
Shroud Cover (23) in the same manner.
7
4
2
80
18
103
100
78
78
9
6
8. Attach the top of the Left Shroud (21) to the Top
Frame (4) with two M4 x 12mm Self-tapping
Screws (102).
Repeat this step for the Right Shroud (22).
8
9
23
7. Attach the Top Frame (4) to the Upright (2) with
t
wo M8 x 80mm Bolts (100), two M8 Washers
(103), and two M8 Nylon Locknuts (78). Do not
tighten the Nylon Locknuts yet.
Attach the Weight Guides (18) to the Top Frame
(4) with two M10 x 20mm Button Screws (96) and
two M10 Washers (80).
102
21
23
21
94
94
114
107
110
110
104
114
22
4
22
4
To Next Page
